TASK 53-05-03-210-812
14. INTERNAL - GENERAL VISUAL: ELECTRICAL AND ELECTRONICS COMPARTMENT
(Figure 216)
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
118 Electrical and Electronics Compartment - Right
B. Access Panels
Number Name/Location
117A Electronic Equipment Access Door
S1102 Electrical And Electronics Compartment Inspection
C. Inspection
SUBTASK 53-05-03-010-010
(1) Open these access panels:
Number Name/Location
117A Electronic Equipment Access Door
S1102 Electrical And Electronics Compartment Inspection
NOTE: Remove LRUs and racks, do not remove permanently installed structure.
Remove/displace insulation blankets as required.
SUBTASK 53-05-03-210-012
(2) Do a General Visual inspection of the EE compartment (STA 294.5 to 396 (STA 400 for
737-700C and 737-800BCF)), including:
1. Skin panels (skins, frames, stringers), longitudinal lap splices, circumferential skin and
stringer splices, bulkhead at STA 294.5.
2. EE compartment door and airstairs door cutout surround structure.
3. Forward entry and galley door cutout surround structure (portion in lower lobe).
SUBTASK 53-05-03-910-014
(3) 737-6789 Basic Task Description, AMM Task 51-05-01-210-808.
SUBTASK 53-05-03-410-010
(4) Close these access panels:
Number Name/Location
117A Electronic Equipment Access Door
S1102 Electrical And Electronics Compartment Inspection
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 242
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
