SUBTASK 24-31-21-020-002-002
(2) Remove the battery charger [1] per the steps that follow:
(a) Remove the electrical connector from the front of the battery charger [1].
(b) Remove the screw [9] and washer [8] from the terminal block cover [10].
(c) Remove the terminal block cover [10] from the front of the battery charger [1].
(d) Remove the nut [2], lockwasher [3] and washer [4] from the terminal stud.
(e) Remove the nut [7], lockwasher [6] and washer [5] from the terminal stud.
(f) Remove the wires from the terminals.
(g) Remove the battery charger [1]. To remove the battery charger [1], do this task: E/E Box
Removal, TASK 20-10-07-000-801.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-21
Config 2
Page 403
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401,
402, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510,
512-516, 518-520, 523-528, 530-533, 535-537, 541, 542, 552-557, 559-564,
567-569, 571-577, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615,
620, 625-627, 671, 672, 686, 691-699, 703, 803-813, 821, 822, 831-838, 841, 842,
851, 852, 854-858, 861-863, 871-874, 947, 948, 968-973, 980-999
