(a) If the first officer's window receptacle connector keyway is not set at the right position, or
3 o'clock, do the steps that follow:
1) Remove the four screws [5] to remove the first officer's window cover.
2) Remove the four screws [3] and four washers [2] at the window receptacle
connector.
3) Turn the window receptacle connector keyway to the right position, or 3 o'clock, and
install the screws and washers.
4) Install the first officer's window cover.
SUBTASK 30-41-00-210-006
(9) Examine the first officer's coil cord for signs of rub damage at the connector ends.
(a) Do this task: General Visual Inspection of EWIS, TASK 20-60-04-100-801.
SUBTASK 30-41-00-420-002
(10) Install the coil cord on the first officer's side of the flight compartment.
NOTE: The cord is reversible.
(a) Use best fit for left or right installation.
F. Put the Airplane Back to its Normal Condition
SUBTASK 30-41-00-860-015
(1) Remove the safety tags and close these circuit breakers:
CAPT Electrical System Panel, P18-3
Row Col Number Name
D 2 C00225 WINDOW HEAT CONTROL LEFT SIDE AC
E 2 C00227 WINDOW HEAT CONTROL RIGHT SIDE AC
F/O Electrical System Panel, P6-11
Row Col Number Name
B 8 C00393 WINDOW HEAT POWER RIGHT SIDE
F/O Electrical System Panel, P6-12
Row Col Number Name
B 9 C00392 WINDOW HEAT POWER LEFT SIDE
SUBTASK 30-41-00-710-002
(2) Do this task: Window Heat System - Operational Test, TASK 30-41-00-710-801.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
30-41-00
Page 603
D633A101-ILF Oct 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
