B. Inspection
NOTE: Removal of external antenna fairings are required.
SUBTASK 53-05-02-211-193
(1) Do a Detailed inspection of the exterior surface of the skin under the TCAS Antenna at STA
385, RBL 5.
See Doc D626A001-DTR, DTR check form 53-30-01-4A for alternative inspections.
END OF TASK
TASK 53-05-02-211-815
40. INTERNAL - DETAILED: SATCOM AERO-H ANTENNA INSTALLATION
NOTE: This procedure is a scheduled maintenance task.
A. General
B. Location Zones
Zone Area
231 Forward Passenger Compartment - Forward Entry Door to Sta 663.75 - Left
232 Forward Passenger Compartment - Forward Entry Door to Sta 663.75 - Right
C. Inspection
NOTE: Removal of antenna is required.
SUBTASK 53-05-02-211-015
(1) Do a Detailed inspection of the skin near the fastener locations around the antenna cutout,
stringers, and antenna nutplates on both the left and right sides of the aircraft at Sta 500
between stringers S-6 and S-7.
See Doc D626A001-DTR, DTR check form 53-30-01-5 for alternative inspections.
END OF TASK
TASK 53-05-02-210-801
41. EXTERNAL - GENERAL VISUAL: FUSELAGE SIDE SKIN PANELS
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
191 Lower Wing-To-Body Fairing - Forward of Wing Box
195 Above Wing, Wing-To-Body Fairing - Left
196 Above Wing, Wing-To-Body Fairing - Right
231 Forward Passenger Compartment - Forward Entry Door to Sta 663.75 - Left
232 Forward Passenger Compartment - Forward Entry Door to Sta 663.75 - Right
B. Access Panels
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
191AR Forward Wing To Body Fairing Panel - Upper
195AL Wing To Body Fairing - Left Side
195AR Wing To Body Fairing - Right Side
195BL Wing To Body Fairing - Left Side
195BR Wing To Body Fairing - Right Side
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-02
Page 220
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
