WING-TO-BODY FAIRING PANELS - REMOVAL/INSTALLATION
1. General
A. This procedure has these tasks:
(1) A removal of the Forward Wing-To-Body fairings panels.
(2) An installation of the Forward Wing-To-Body fairings panels.
(3) A removal of the Center Wing-To-Body fairings panels.
(a) This includes the Wing-To-Body fairing panels above the wings.
(4) An installation of the Center Wing-To-Body fairings panels.
(a) This includes the Wing-To-Body fairing panels above the wings.
(5) A removal of the Aft Wing-To-Body fairings panels.
(6) An installation of the Aft Wing-To-Body fairings panels.
TASK 53-51-21-000-803
2. Forward Wing-To-Body Fairing Panel Removal
(Figure 401)
A. References
Reference Title
21-51 PACK FLOW CONTROL AND PACK COOLING SYSTEM
33-44 ANTI-COLLISION LIGHTS
51-31-00-160-801 Prepare For Sealing (P/B 201)
B. Location Zones
Zone Area
191 Lower Wing-To-Body Fairing - Forward of Wing Box
C. Access Panels
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
191AR Forward Wing To Body Fairing Panel - Upper
191BL Forward Wing To Body Fairing Panel, Ram Air Inlet
191BR Forward Wing To Body Fairing Panel, Ram Air Inlet
191CL Forward Wing To Body Fairing Panel - Middle
191CR Forward Wing To Body Fairing Panel - Middle
191D Forward Wing To Body Fairing Panel - Lower
191E Low Pressure ECS Panel - Forward
191FL Forward Wing To Body Fairing Panel - Mid Fairing, Above Ram Air Inlet
191FR Forward Wing To Body Fairing Panel - Mid Fairing, Above Ram Air Inlet
191GL Ram Air Actuator Panel - Forward
191GR Ram Air Actuator Panel - Forward
191HL Ram Air Inlet Lip Panel - Forward
191HR Ram Air Inlet Lip Panel - Forward
D. Prepare for Forward Wing-To-Body Fairing Panels Removal Procedure
SUBTASK 53-51-21-020-002
(1) If necessary, remove or disconnect the equipment that is attached to the fairing.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-51-21
Page 401
D633A101-ILF Oct 15/2014
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
