TASK 76-11-03-400-804-F00
7. Control Stand Cover and Stop Installation
(Figure 403)
A. General
(1) This task provides the instructions on how to install the control stand cover and stop.
B. Location Zones
Zone Area
211 Flight Compartment - Left
212 Flight Compartment - Right
C. Control Stand Cover and Stop Installation
SUBTASK 76-11-03-420-006-F00
(1) Install the right side cover assembly [48] as follows:
(a) Install the right side cover assembly [48].
1) Install the six screws [49].
2) Put the switch into the right side cover assembly [48].
3) Install the nut [41]].
4) Install the cutout switch knob [42] for the stabilizer trim horn:
SUBTASK 76-11-03-420-009-F00
(2) Install the left side cover assembly as follows:
(a) Put the left side cover assembly in its position.
(b) Install the six screws [50].
SUBTASK 76-11-03-420-007-F00
(3) Install the forward thrust stop [43] as follows:
(a) Put the forward thrust stop [43] in its position
(b) Install the five screws [40].
SUBTASK 76-11-03-420-010-F00
(4) Install aft thrust stop [44] as follows:
NOTE: Make sure that the aft thrust stop is in the correct position. If the aft thrust stop is
turned 180 degrees, the thrust reverser will not operate.
(a) Make sure that the tabs on the aft thrust stop [44] point aft and down.
(b) Install the three screws [45].
D. Put the Airplane Back to Its Usual Condition
SUBTASK 76-11-03-410-002-F00
(1) Do this task: Control Stand Seal, Spacer and Retainer Installation,
TASK 76-11-03-400-802-F00.
SUBTASK 76-11-03-410-003-F00
(2) Do this task: Control Stand Lightplate Installation, TASK 76-11-03-420-801-F00.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-03
Page 416
D633A101-ILF Feb 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
