Power Distribution Panel Number 1, P91
Row Col Number Name
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406, 409,
410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510, 512-516, 518-520, 523-528, 530-533,
535-537, 541, 542, 552-557, 559-561, 563, 564, 567-569, 571-577, 581, 583, 585, 589, 590, 597-599,
601-603, 606, 607, 610-615, 620, 625-627, 671, 672, 691-699, 703, 803-813, 821, 822, 831, 832,
835-838, 841, 842, 851, 852, 857, 858, 947, 948, 968-973, 980-999
E 3 C00922 AUX BAT CHGR
Power Distribution Panel Number 2, P92
Row Col Number Name
ILF ALL
E 1 C00809 BAT CHGR
Standby Power Control Unit, M01720
Row Col Number Name
B 1 C01410 SPCU NORMAL
E. DC Generation System - Tryout
NOTE: This tryout is to make sure the DC Generation System is in a zero energy state.
SUBTASK 24-31-00-860-005
(1) Make sure that these circuit breakers are open and have safety tags:
Battery Shield, J9
Row Col Number Name
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406, 409,
410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510, 512-516, 518-520, 523-528, 530-533,
535-537, 541, 542, 552-557, 559-561, 563, 564, 567-569, 571-577, 581, 583, 585, 589, 590, 597-599,
601-603, 606, 607, 610-615, 620, 625-627, 671, 672, 691-699, 703, 803-813, 821, 822, 831, 832,
835-838, 841, 842, 851, 852, 857, 858, 947, 948, 968-973, 980-999
A 3 C01209 AUX BAT CHARGER
ILF ALL
A 4 C00142 BATTERY CHARGER
A 5 C01340 BATTERY BUS
Power Distribution Panel Number 1, P91
Row Col Number Name
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406, 409,
410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510, 512-516, 518-520, 523-528, 530-533,
535-537, 541, 542, 552-557, 559-561, 563, 564, 567-569, 571-577, 581, 583, 585, 589, 590, 597-599,
601-603, 606, 607, 610-615, 620, 625-627, 671, 672, 691-699, 703, 803-813, 821, 822, 831, 832,
835-838, 841, 842, 851, 852, 857, 858, 947, 948, 968-973, 980-999
E 3 C00922 AUX BAT CHGR
Power Distribution Panel Number 2, P92
Row Col Number Name
ILF ALL
E 1 C00809 BAT CHGR
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-00
Page 202
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
