PASSENGER ENTRY DOOR SCUFF PLATE - REMOVAL/INSTALLATION
1. General
A. This procedure contains these tasks:
(1) The removal of the passenger entry door scuff plates.
(2) The installation of the passenger entry door scuff plates.
TASK 53-11-01-000-801
2. Remove the Scuff Plate
(Figure 401, Figure 402, Figure 403)
A. Tools/Equipment
Reference Description
STD-1064
Scraper - Phenolic, Hard Resin
B. Consumable Materials
Reference Description Specification
B00148 Solvent - Methyl Ethyl Ketone (MEK) ASTM D740
C. Location Zones
Zone Area
830 Subzone - Passenger Compartment Doors, Left
840 Subzone - Passenger Compartment Doors, Right
D. Procedure
SUBTASK 53-11-01-020-001
(1) Remove the scuff plate:
(a) Remove the fasteners that attach the scuff plate to structure.
(b) Use a hard resin phenolic scraper, STD-1064 to release the scuff plate from structure.
(c) Remove the scuff plate.
NOTE: The door lining attached to the scuff plate is installed with a parting agent on the
scuff plate for separation and removal of the scuff plate. It is possible to remove
the door lining attached to the scuff plate with the scuff plate.
WARNING
DO NOT GET SOLVENTS IN YOUR MOUTH OR EYES, OR ON YOUR
SKIN. DO NOT BREATHE THE FUMES FROM THE SOLVENTS.
SOLVENTS ARE HAZARDOUS MATERIALS. REFER TO PRODUCT
SAFETY DATA SHEETS (MSDS) AND LOCAL REQUIREMENTS FOR
PROPER HANDLING PROCEDURES.
(d) Remove sealant and parting agent from faying surfaces with solvent, B00148 and hard
resin phenolic scraper, STD-1064.
(e) Do a visual inspection of the nut plates to determine if they are in acceptable condition. If
it is necessary, replace them.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-11-01
Page 401
D633A101-ILF Oct 15/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
