(Continued)
AMM Item Description AIPC Reference AIPC Effectivity
1 (cont.) 24-21-21-47A-400 ILF 151, 156-199, 401,
416, 496-500, 526, 541,
542, 560, 561, 563, 564,
567-569, 581, 583, 585,
588-590, 592-599,
601-603, 606, 607,
610-615, 620, 625-627,
671, 672, 686, 691-699,
813, 833-835, 838,
854-856, 861-863,
871-874, 948, 971
24-21-21-47B-425 ILF 101, 304, 308,
317-319, 323, 331-399,
501, 504, 516, 533, 535,
537, 552, 562, 812,
980-999
D. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
121 Forward Cargo Compartment - Left
E. Prepare for Installation.
SUBTASK 24-61-01-860-002
WARNING
REMOVE ELECTRICAL POWER BEFORE YOU REMOVE OR INSTALL
COMPONENTS IN THE POWER DISTRIBUTION PANELS. THERE ARE HIGH
VOLTAGES THAT CAN CAUSE INJURIES TO PERSONNEL AND DAMAGE TO
EQUIPMENT.
(1) Make sure that electrical power is removed.
F. Procedure
SUBTASK 24-61-01-420-001
(1) Do these steps to install the relay [1]:
WARNING
MAKE SURE THAT ALL OF THE POWER WARNING LIGHTS ON THE
POWER DISTRIBUTION PANEL ARE OFF. THERE ARE HIGH VOLTAGES
IN THE POWER DISTRIBUTION PANEL THAT CAN CAUSE INJURIES TO
PERSONNEL.
(a) Make sure that all of the power warning lights on the power distribution panel are off.
(b) Put the relay [1] in position.
(c) Install the four nuts [4] and washers [5] that hold the relay to the power distribution panel.
(d) Install the electrical wires on lower terminal studs as specified by the identification tags.
(e) Install the nut [6] and lock washer [7] on each electrical wire.
(f) Remove the identification tags from the wires.
(g) Install the terminal cover [3].
(h) Install the two screws [2] that hold the terminal cover.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-61-01
Page 409
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
