(Continued)
Zone Area
242 Aft Passenger Compartment - Station 663.75 to Aft Pressure Bulkhead - Right
B. Access Panels
Number Name/Location
194AL Aft Wing To Body Fairing Panel
194FL Aft Wing To Body Fairing Panel
194GL Aft Wing To Body Fairing Panel
194GR Aft Wing To Body Fairing Panel
C. Inspection
SUBTASK 53-05-02-010-012
(1) Open these access panels:
Number Name/Location
194AL Aft Wing To Body Fairing Panel
194FL Aft Wing To Body Fairing Panel
194GL Aft Wing To Body Fairing Panel
194GR Aft Wing To Body Fairing Panel
NOTE: Remove or displace wing to body fairings as required to perform the inspection.
SUBTASK 53-05-02-210-005
(2) Do a General Visual inspection of the skin from STA 727 to STA 887 between stringers S-14 to
S-17. (PSE 53-60-02-1).
See Doc D626A001-DTR, DTR check form 53-30-02-1 for alternative inspections.
SUBTASK 53-05-02-410-010
(3) Close these access panels:
Number Name/Location
194AL Aft Wing To Body Fairing Panel
194FL Aft Wing To Body Fairing Panel
194GL Aft Wing To Body Fairing Panel
194GR Aft Wing To Body Fairing Panel
END OF TASK
TASK 53-05-02-211-868
186. EXTERNAL - DETAILED: FUSELAGE SIDE SKIN PANELS UNDER THE WING-TO-BODY FAIRING
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
194 Lower Wing-To-Body Fairing - Aft of Wheel Well
B. Access Panels
Number Name/Location
194AL Aft Wing To Body Fairing Panel
194AR Aft Wing To Body Fairing Panel
194FL Aft Wing To Body Fairing Panel
194FR Aft Wing To Body Fairing Panel
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-02
Page 298.16
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
