ILF ALL; AUTOTHROTTLE SWITCHPACK WITH REPLACEABLE SWITCHES P/N 254A1150-1, -2, -7, -8, -9, -10
TASK 76-11-07-020-801-F00
3. Autothrottle Switchpack Switch Removal
(Figure 401)
A. General
(1) This task provides the instructions on how to remove an autothrottle switchpack switch from
the autothrottle switchpack assembly.
(2) There are nine switches installed in each switchpack.
(3) There are six switches that can be removed with the autothrottle switchpack assembly
installed.
(4) For switches S3, S4 and S7 (if the switchpack is still installed), you must remove the applicable
switchpack to remove the switch.
(5) This is a list of the switch number, subject and the System Schematic Manual (SSM)
(Table 401).
Table 401/76-11-07-993-804-F00
SWITCH SUBJECT SSM
ENGINE 1 SWITCHPACK
S1
S1
S2
S3
S4
S5
S6
S7
S8
S8
S9
Auto Ground Speedbrake Control
Landing Gear Warning
Autobrake System
Autobrake System
ENG 1 T/R Synchronous Shaft Locks
ENG 1 Thrust Reverser Control
ENG 1 Thrust Reverser Control
Wing Thermal Anti-Ice System
Aural Warning - Takeoff Warning
Weather Radar
Landing Gear Warning
27-62-11
32-61-21
32-42-11
32-42-11
78-32-51
78-34-11
78-34-11
30-11-11
31-53-11
34-41-11
32-61-21
ENGINE 2 SWITCHPACK
S1
S1
S2
S3
S4
S5
S6
S7
S8
S8
S9
Auto Ground Speedbrake Control
Landing Gear Warning
Autobrake System
Autobrake System
ENG 2 T/R Synchronous Shaft Locks
ENG 2 Thrust Reverser Control
ENG 2 Thrust Reverser Control
Wing Thermal Anti-Ice System
Aural Warning - Takeoff Warning
Weather Radar
Landing Gear Warning
27-62-11
32-61-21
32-42-11
32-42-11
78-32-61
78-34-21
78-34-21
30-11-11
31-53-11
34-41-11
32-62-21
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-07
Page 411
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
