TASK 24-41-11-200-804
3. External Power Receptacle - External Inspection
(Figure 601 or Figure 602 or Figure 603)
NOTE: This procedure is a scheduled maintenance task.
A. General
(1) The external power receptacle is located on the lower right hand side of the airplane. It is
installed forward of the nose gear wheel well.
B. References
Reference Title
24-22-00-860-812 Remove Electrical Power (P/B 201)
C. Location Zones
Zone Area
116 Nose Landing Gear Wheel Well - Right
D. Access Panels
Number Name/Location
114AR External Power Receptacle Door
E. Procedure
SUBTASK 24-41-11-860-009
(1) Do this task: Remove Electrical Power, TASK 24-22-00-860-812.
SUBTASK 24-41-11-010-012
(2) Open this access panel:
Number Name/Location
114AR External Power Receptacle Door
SUBTASK 24-41-11-860-010
(3) Remove external power plug from receptacle, if it is installed.
SUBTASK 24-41-11-210-003
(4) Do these steps to examine the receptacles from the outer side of the airplane:
(a) Make sure the pins are not loose.
(b) Look for pins that are bent or have a crack.
(c) Look for damage or cracks on the base insulation.
(d) Look for discolored, burned, or pitted pins.
SUBTASK 24-41-11-410-007
(5) Close this access panel:
Number Name/Location
114AR External Power Receptacle Door
END OF TASK
