(i) Install the screws [5] that attach the scuff plate [4] to the structure.
1) Apply BMS 5-95, P/S 870 Class B-1/2 sealant, A50250 orsealant, A50419 to the
screws [5].
2) Torque the screws [5] to an 18 in-lb (2 N·m) to 22 in-lb (2 N·m).
SUBTASK 53-11-02-390-001
(5) Remove excess sealant from the gap and the edge after squeeze-out has stopped.
SUBTASK 53-11-02-390-002
(6) Apply 3M EC-3587B compound, A01024 to the gaps and fastener recesses common to the
door seal, as follows:
(a) Clean areas to be filled with solvent, B00148 or solvent, B00666.
(b) Fill the gaps and fastener recesses that are common to the door seal with 3M EC-3587B
compound, A01024 and fair flush with adjacent surfaces.
(c) Sand the filled areas smooth and flush with adjacent surfaces.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-11-02
Page 411
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
