The NDI method(s) necessary to accomplish the intent of this inspection is contained in the
737 Nondestructive Test Manual (D6-37239). The inspection procedures are contained in Part
6, Section 53-11-22.
SUBTASK 53-05-02-410-097
(3) Close this access panel:
Number Name/Location
822 Aft Cargo Door
END OF TASK
TASK 53-05-02-130-806
129. INTERNAL - SPECIAL DETAILED: AFT CARGO DOOR SURROUND FORWARD AND AFT EDGE
FRAMES AT BS 794.37 AND BS 847
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
142 Aft Cargo Compartment - Right
144 Area Below Aft Cargo Compartment - Right
B. Access Panels
Number Name/Location
822 Aft Cargo Door
C. Inspection
SUBTASK 53-05-02-010-006
(1) Open this access panel:
Number Name/Location
822 Aft Cargo Door
NOTE: Aft cargo door must be open to perform the inspection. Remove or displace aft cargo
lining as required to perform the inspection.
SUBTASK 53-05-02-130-006
(2) Do an Ultrasonic inspection of the outboard portion of the frame web under the door stop
fittings and sill clips at STA 794.37 and STA 847.
See Doc D626A001-DTR, DTR check form 53-60-08-5 for alternative inspections.
The NDI method(s) necessary to accomplish the intent of this inspection is contained in the
737 Nondestructive Test Manual (D6-37239). The inspection procedures are contained in Part
4, Section 53-10-08.
SUBTASK 53-05-02-410-004
(3) Close this access panel:
Number Name/Location
822 Aft Cargo Door
END OF TASK
TASK 53-05-02-250-892
130. INTERNAL - SPECIAL DETAILED: AFT CARGO DOOR SURROUND STRUCTURE
NOTE: This procedure is a scheduled maintenance task.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-02
Page 283
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
