ILF ALL
TASK 53-05-03-210-804
4. EXTERNAL - GENERAL VISUAL: NOSE WHEEL WELL
(Figure 204)
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
115 Nose Landing Gear Wheel Well - Left
116 Nose Landing Gear Wheel Well - Right
B. Inspection
SUBTASK 53-05-03-210-004
(1) Do a General Visual inspection of the nose landing gear wheel well, including canted bulkhead
(Sta 224.8 to 227.8), Sta 294.5 bulkhead, side and top panels, trunnion support fitting, actuator
support fitting, and drag brace fitting.
SUBTASK 53-05-03-910-004
(2) 737-6789 Basic Task Description, AMM Task 51-05-01-210-806.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 207
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
