TASK 53-05-03-210-838
49. INTERNAL - GENERAL VISUAL: AREA AFT OF STA 1016 BULKHEAD
(Figure 255)
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
311 Area Aft of Pressure Bulkhead - Left
312 Area Aft of Pressure Bulkhead - Right
B. Access Panels
Number Name/Location
311BL Stabilizer Trim Access Door
C. Inspection
SUBTASK 53-05-03-010-035
(1) Open this access panel:
Number Name/Location
311BL Stabilizer Trim Access Door
SUBTASK 53-05-03-210-038
(2) Do a General Visual inspection of the area aft of STA 1016 pressure bulkhead to STA 1088,
including:
1. Skin panels (skins, frames and stringers), longitudinal lap splices, circumferential skin and
stringer splices.
2. Aft side of STA 1016 bulkhead (chords, pressure web, stiffeners, chord/web attachments).
3. Stringer splice fittings and tension bolts at STA 1016.
4. STA 1088 bulkhead, including vertical fin rear spar fittings and horizontal stabilizer center
section jackscrew fitting lugs and bolts.
SUBTASK 53-05-03-910-067
(3) 737-6789 Basic Task Description, AMM Task 51-05-01-210-806.
SUBTASK 53-05-03-410-035
(4) Close this access panel:
Number Name/Location
311BL Stabilizer Trim Access Door
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 298.66
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
