(Continued)
AMM Item Description AIPC Reference AIPC Effectivity
2 Packing 80-11-01-01-100 ILF 101, 151, 156-199,
301, 304, 308, 310, 314,
315, 317-319, 323,
331-399, 401, 402, 406,
409, 410, 412, 416, 424,
425, 427-429, 451, 452,
491-498, 501-504,
507-510, 512-516,
518-520, 523-528,
530-533, 535-537, 541,
542, 552-557, 559,
571-577, 583, 671, 672,
686, 703, 707-710,
804-807, 812, 821, 822,
831, 832, 836, 837, 841,
842, 851, 852, 854-858,
861-863, 871-874, 947,
968, 969
80-11-01-01A-110 ILF 317, 406, 424, 425,
427-429, 499, 500,
560-564, 567-569, 581,
583, 585, 588-590,
592-599, 601-603, 606,
607, 610-615, 620,
625-627, 691-699,
833-835, 838, 948,
970-973, 980-999
E. Location Zones
Zone Area
411 Engine 1 - Engine
421 Engine 2 - Engine
F. QAD Adapter Installation
SUBTASK 80-11-02-400-001-F00
(1) Install the QAD adapter [1] as follows:
WARNING
DO NOT LET OIL STAY ON YOUR SKIN. YOU CAN ABSORB
POISONOUS MATERIALS FROM THE OIL THROUGH YOUR SKIN.
(a) Lightly lubricate a new packing [2] with the oil, D00599 [CP2442].
(b) Install the packing [2] in the QAD adapter [1].
(c) Install the QAD adapter [1] in the AGB.
(d) Lightly lubricate the threads of the bolts [4] with the graphite compound, D00601
[CP2101].
(e) Install the eight bolts [4] and the washers [3] in the AGB.
(f) Tighten the bolts [4] to 209-231 inch-pounds (23.75-26.25 Newton-meters).
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
80-11-02
Page 405
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
