Boeing 737-600 - Task 53-05-03-210-844 - INTERNAL - GENERAL VISUAL: VERTICAL FIN REAR SPAR FITTING; Subtask 53-05-03-010-041; Subtask 53-05-03-210-044; Subtask 53-05-03-910-073

TASK 53-05-03-210-844
55. INTERNAL - GENERAL VISUAL: VERTICAL FIN REAR SPAR FITTING
(Figure 261)
NOTE: This procedure is a scheduled maintenance task.
A. References
Reference Title
51-05-01-210-806 737-6789 Basic Task Description (P/B 201)
B. Location Zones
Zone Area
323 Vertical Fin - Front Spar To Rear Spar
C. Access Panels
Number Name/Location
323AL Vertical Fin, Front Spar Access Door
323AR Vertical Fin, Front Spar Access Door
323BL Vertical Fin, Forward Fin Access Door
323BR Vertical Fin, Forward Fin Access Door
323CL Vertical Fin, Rear Spar Access Door
323CR Vertical Fin, Rear Spar Access Door
D. Inspection
SUBTASK 53-05-03-010-041
(1) Open these access panels:
Number Name/Location
323AL Vertical Fin, Front Spar Access Door
323AR Vertical Fin, Front Spar Access Door
323BL Vertical Fin, Forward Fin Access Door
323BR Vertical Fin, Forward Fin Access Door
323CL Vertical Fin, Rear Spar Access Door
323CR Vertical Fin, Rear Spar Access Door
SUBTASK 53-05-03-210-044
(2) Do a General Visual inspection of the vertical fin rear spar fitting lugs and bolts at Sta 1088.
Inspect fuselage skin under vertical fin from Sta 1016 to 1088.
SUBTASK 53-05-03-910-073
(3) 737-6789 Basic Task Description, TASK 51-05-01-210-806.
SUBTASK 53-05-03-410-041
(4) Close these access panels:
Number Name/Location
323AL Vertical Fin, Front Spar Access Door
323AR Vertical Fin, Front Spar Access Door
323BL Vertical Fin, Forward Fin Access Door
323BR Vertical Fin, Forward Fin Access Door
323CL Vertical Fin, Rear Spar Access Door
323CR Vertical Fin, Rear Spar Access Door
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 298.87
D633A101-ILF Oct 15/2019
