TASK 53-05-03-210-824
26. INTERNAL - GENERAL VISUAL: AFT CARGO COMPARTMENT
(Figure 228)
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
141 Aft Cargo Compartment - Left
142 Aft Cargo Compartment - Right
B. Access Panels
Number Name/Location
S1401 AFT Cargo Compartment Inspection
C. Inspection
SUBTASK 53-05-03-010-021
(1) Open this access panel:
Number Name/Location
S1401 AFT Cargo Compartment Inspection
NOTE: Remove sidewall and ceiling panels, E6 LRU, access panels around vacuum lav tank.
Remove/displace insulation blankets as required. Remove/displace vacuum lav
components as required. Remove/displace auxiliary fuel tank as required (business jet
only).
SUBTASK 53-05-03-210-024
(2) Do a General Visual inspection of the aft cargo compartment, including:
1. Side skin panels (skin, frames, stringers), circumferential skin and stringer splices, (note:
located at Sta 727I for -900 and 727L for -900ER models).
2. Stringer 18 strap at side of body.
3. Stringer 18A web, chord and links.
4. Aft side of STA 727 bulkhead and pressure web.
5. For the -800BCF, frame reinforcements at STA 727B to STA 867 at S-17 to S-21 (Note:
frame reinforcements on LH side only at STA 807 to STA 847), STA 747 shear ties at S-18R/L
to S-20R/L, STA 847 shear tie at S-18L to S-19L, STA 887 frame reinforcements at S-17 to
S-21 and floor beam reinforcements, and frame fitting and rail support at STA 907 at S-15 to
S-17.
SUBTASK 53-05-03-910-025
(3) 737-6789 Basic Task Description, AMM Task 51-05-01-210-808.
SUBTASK 53-05-03-410-021
(4) Close this access panel:
Number Name/Location
S1401 AFT Cargo Compartment Inspection
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 287
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
