ILF 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 424, 425, 427-429, 502, 503, 507, 514,
524, 533, 535, 537, 556, 557, 568, 583, 588, 592-596, 671, 672, 707-710, 832, 836, 837, 841, 842,
968-970, 972, 973, 980-999; ILF 101, 156-199, 409, 410, 416, 451, 501, 504, 508, 513, 515, 516, 518,
531, 532, 536, 541, 542, 552, 571-574, 576, 686, 803-813, 821, 822, 831, 854-856, 861-863, 871-873
PRE SB 737-56-1017; ILF 412 POST SB 737-30-1046 OR PRE SB 737-56-1017
SUBTASK 30-41-31-010-001
(2) Remove the trim from around the number 5 window.
D. Thermal Switch Removal
SUBTASK 30-41-31-020-001
(1) Remove the thermal switch [2].
(a) Disconnect the electrical leads [1] from the thermal switch [2].
(b) Pull the spring from the thermal switch [2].
(c) Remove the thermal switch [2] from the window.
NOTE: Be careful not to damage the fairing compound. If the switch does not come off
by hand, you may tap the switch side with a no bounce hammer. If you use a
hammer to remove the switch, you will have to discard the switch.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
30-41-31
Page 403
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 424, 425, 427-429,
502, 503, 507, 514, 524, 533, 535, 537, 556, 557, 568, 583, 588, 592-596, 671, 672,
707-710, 832, 836, 837, 841, 842, 968-970, 972, 973, 980-999; ILF 101, 156-199,
409, 410, 416, 451, 501, 504, 508, 513, 515, 516, 518, 531, 532, 536, 541, 542,
552, 571-574, 576, 686, 803-813, 821, 822, 831, 854-856, 861-863, 871-873 PRE
SB 737-56-1017; ILF 412 POST SB 737-30-1046 OR PRE SB 737-56-1017
