STABILIZER TO BODY FRONT SPAR SLIDING SEAL - REMOVAL/INSTALLATION
1. General
A. This procedure contains two tasks:
(1) The removal of the stabilizer-to-body front spar sliding seal.
(2) The installation of the stabilizer-to-body front spar sliding seal (referred to as the sliding seal).
B. The sliding seal closes the opening where the attach fitting of the forward stabilizer moves. You can
do the approved repair of the seal when you remove the seal plates and, do this task: Apply The
Abrasion-Resistant Teflon Finish, BMS 10-86 Type I, TASK 51-21-81-370-801.
TASK 53-31-31-000-801
2. Stabilizer-to-Body Front Spar Sliding Seal Removal
(Figure 401)
A. References
Reference Title
27-31-00-800-802 Remove Pressure from the Elevator Hydraulic Systems A and B
(P/B 201)
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-1672 Assembly - Lock, Stabilizer Trim
737-600, -700, -800
Part #: F71336-501 Supplier: 81205
C. Location Zones
Zone Area
300 Empennage
D. Prepare for Removal
SUBTASK 53-31-31-860-038-001
(1) Do this task: Remove Pressure from the Elevator Hydraulic Systems A and B,
TASK 27-31-00-800-802.
SUBTASK 53-31-31-860-039-001
(2) Set the stabilizer trim cutout switches to the CUTOUT position.
NOTE: The stabilizer trim cutout switches are installed on the control stand.
SUBTASK 53-31-31-860-040-001
(3) Open these circuit breakers and install safety tags:
CAPT Electrical System Panel, P18-1
Row Col Number Name
C 2 C00849 AFCS STABILIZER TRIM
CAPT Electrical System Panel, P18-2
Row Col Number Name
C 8 C00544 FLIGHT RECORDER POSITION SENSOR
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-31-31
Config 1
Page 401
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 301, 304, 308, 310, 314, 315, 317-319, 323, 331, 405,
406, 409, 410, 416, 424, 427-429, 451, 501-504, 507, 508,
512-516, 518-520, 524, 531-533, 535-537, 541, 542, 552,
571, 572, 703, 707-710, 803 PRE SB 737-53-1252
