(b) Remove the thermal switch [2] from the duct [4].
NOTE: Use a second wrench on the duct [4] when you disconnect the thermal switch [2].
(c) Discard the o-ring [3].
(d) Put a protective cap on the thermal switch port of the duct [4].
H. Functional Test
SUBTASK 47-43-02-720-001
(1) Test the thermal switch [2] (S01129) per the manufacturer's instructions.
NOTE: Do the following installation procedure with either a new or serviceable thermal
switch [2].
I. Install the Thermal Switch
SUBTASK 47-43-02-020-009
(1) Remove the protective cap.
SUBTASK 47-43-02-640-002
(2) Lubricate the new o-ring [3] with water.
SUBTASK 47-43-02-420-005
(3) Install the new o-ring [3] on the thermal switch [2].
SUBTASK 47-43-02-420-006
(4) Carefully install the thermal switch [2] into the thermal switch port.
NOTE: Use a second wrench on the nut attached to the duct [4] when you tighten the thermal
switch [2].
SUBTASK 47-43-02-420-007
(5) Tighten the thermal switch [2] to 100 ±10 in-lb (11 ±1 N·m).
(a) Put a lockwire on the thermal switch [2] and the duct [4] (TASK 20-10-44-400-801).
SUBTASK 47-43-02-420-008
(6) Connect the electrical connector [1] to the thermal switch [2].
SUBTASK 47-43-02-210-002
(7) Make sure that there is a shield band on the electrical connector [1].
(a) If there is no shield band, install a shield band on the electrical connector [1] (SWPM
20-25-14 and SWPM 20-25-15).
(b) If the shield band is damaged, repair the shield band (SWPM 20-25-14 and SWPM
20-25-15).
J. Operational Test of the Thermal Switch
SUBTASK 47-43-02-860-006
(1) Remove the safety tags and close these circuit breakers:
CAPT Electrical System Panel, P18-3
Row Col Number Name
ILF 402, 452, 509, 510, 523, 525-528, 576, 577, 971; ILF 101, 151, 156-199, 301, 304, 308, 310, 314,
315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507,
508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672,
686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
