TASK 76-11-03-400-802-F00
5. Control Stand Seal, Spacer and Retainer Installation
(Figure 402)
A. General
(1) This task provides the instructions on how to install the control stand seals, spacers and
retainers in the control stand.
B. Location Zones
Zone Area
211 Flight Compartment - Left
212 Flight Compartment - Right
C. Control Stand Seal, Spacer, and Retainer Installation
SUBTASK 76-11-03-420-003-F00
(1) Install the right seal [39], the spacer [27], and the seal retainer [37] as follows:
(a) Put the spacer [27] in its position.
(b) Install the right seal [39].
(c) Install the seal retainer [37] on the right seal [39].
(d) Install the four screws [38].
SUBTASK 76-11-03-420-004-F00
(2) Install the upper center seal [36], the spacer [26], and the seal retainer [34] as follow:
(a) Put the spacer [26] in its position.
(b) Put the upper center seal [36] in position between the thrust levers.
(c) Put the seal retainer [34] between the thrust levers.
(d) Install the seal retainer [34] on the seal.
(e) Install the three screws [35].
SUBTASK 76-11-03-420-008-F00
(3) Install the lower center seal [30] and the seal retainer [28] as follow:
(a) Install the lower center seal [30].
(b) Install the seal retainer [28] on the seal.
(c) Install the two screws [39].
SUBTASK 76-11-03-420-005-F00
(4) Install the left seal [33], the spacer [25], and the seal retainer [31] as follow:
(a) Put the spacer [25] in its position.
(b) Install the left seal [33].
(c) Install the seal retainer [31] on the seal.
(d) Install the four screws [32].
D. Put the Airplane Back to Its Usual Condition
SUBTASK 76-11-03-410-001-F00
(1) Do this task: Control Stand Lightplate Installation, TASK 76-11-03-420-801-F00.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-03
Page 413
D633A101-ILF Feb 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
