TASK 76-11-03-400-803-F00
6. Control Stand Cover and Stop Removal
(Figure 403)
A. General
(1) This task provides the instructions on how to remove the control stand cover and stop.
B. Location Zones
Zone Area
211 Flight Compartment - Left
212 Flight Compartment - Right
C. Prepare for the Removal
SUBTASK 76-11-03-010-002-F00
(1) For the applicable control stand lightplate, do this task: Control Stand Lightplate Removal,
TASK 76-11-03-000-801-F00.
SUBTASK 76-11-03-010-003-F00
(2) For the applicable control stand seal, spacer, and retainer, do this task: Control Stand Seal,
Spacer, and Retainer Removal, TASK 76-11-03-400-801-F00.
D. Control Stand Cover and Stop Removal
SUBTASK 76-11-03-020-006-F00
(1) Remove the forward thrust stop [43] as follows:
(a) Remove the five screws [40].
(b) Remove the forward thrust stop [43].
SUBTASK 76-11-03-020-010-F00
(2) Remove the aft thrust stop [44] as follows:
(a) Remove the three screws [45].
(b) Remove the aft thrust stop [44].
SUBTASK 76-11-03-020-007-F00
(3) Remove the right side cover assembly [48] as follows:
(a) Remove the cutout switch knob [42] for the stabilizer trim horn.
(b) Remove the nut [41].
(c) Remove the six screws [49].
(d) Remove the right side cover assembly [48].
SUBTASK 76-11-03-020-009-F00
(4) Remove the left side cover assembly as follows:
(a) Remove the six screws [50].
(b) Remove the left side cover assembly
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-03
Page 414
D633A101-ILF Feb 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
