CAPT Electrical System Panel, P18-3
Row Col Number Name
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590, 592-599,
601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999; ILF 101, 151,
156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416,
424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542,
552-556, 560-562, 567, 571-575, 671, 672, 686, 703, 707-710, 803-813, 821, 822, 831, 832, 836,
837, 841, 842, 851, 852, 854-858, 861-863, 871-874, 947, 948, 968-970, 972, 973 POST SB
737-47-1003
E 15 C01680 NGS ALT PWR
(b) Remove the DO-NOT-OPERATE tags from the L PACK and R PACK selector switches.
(c) Put the L PACK and R PACK selector switches to the AUTO position.
SUBTASK 47-32-04-790-002
(2) Do this task: Leak Check of the Nitrogen Generation System, TASK 47-00-00-790-801.
(a) With the NGS pressurized, do a leak check of the NGS filter assembly [1].
(b) Repair the leaks that you find.
H. Put the Airplane Back to Its Usual Condition
SUBTASK 47-32-04-410-003
(1) Close this access panel:
Number Name/Location
192BL ECS Ram Air Inlet Mixing Duct Panel - Forward
END OF TASK
TASK 47-32-04-000-801
4. NGS Filter Assembly - Removal
(Figure 402)
A. References
Reference Title
36-00-00-860-806 Remove Pressure from the Pneumatic System (P/B 201)
47-00-00-010-801 Nitrogen Generation System (NGS) Precautions (P/B 201)
47-32-05-000-801 Ram Air Valve Removal (P/B 401)
B. Location Zones
Zone Area
131 Center Section Wing Box, Body Station 540.00 to Body Station 663.75 - Left
212 Flight Compartment - Right
C. Access Panels
Number Name/Location
192BL ECS Ram Air Inlet Mixing Duct Panel - Forward
D. Prepare for the Removal
SUBTASK 47-32-04-864-001
(1) Do this task: Remove Pressure from the Pneumatic System, TASK 36-00-00-860-806.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-32-04
Page 410
D633A101-ILF Oct 15/2019
