(a) If the captain's sidewall receptacle connector keyway is not set at the up position, or 12
o'clock, do the steps that follow:
1) Remove the captain's sidewall (TASK 25-11-21-000-801 or
TASK 25-11-21-000-805).
2) Remove the four screws [3] and four washers [2] at the sidewall receptacle
connector.
3) Turn the sidewall receptacle connector keyway to the up position, or 12 o'clock, and
install the screws and washers.
4) Install the captain's sidewall (TASK 25-11-21-400-801 or TASK 25-11-21-400-805).
SUBTASK 30-41-00-210-012
(3) Examine the position of the captain's window receptacle connector keyway.
(a) If the captain's window receptacle connector keyway is not set at the left position, or 9
o'clock, do the steps that follow:
1) Remove the four screws [5] to remove the captain's window cover.
2) Remove the four screws [3] and four washers [2] at the window receptacle
connector.
3) Turn the window receptacle connector keyway to the left position, or 9 o'clock, and
install the screws and washers.
4) Install the captain's window cover.
SUBTASK 30-41-00-210-005
(4) Examine the captain's coil cord for signs of rub damage at the connector ends.
(a) Do this task: General Visual Inspection of EWIS, TASK 20-60-04-100-801.
SUBTASK 30-41-00-420-001
(5) Install the coil cord on the captain's side of the flight compartment.
NOTE: The cord is reversible.
(a) Use best fit for left or right installation.
SUBTASK 30-41-00-020-002
(6) Remove the coil cord on the first officer's side of the flight compartment.
SUBTASK 30-41-00-210-004
(7) Examine the position of the first officer's sidewall receptacle connector keyway.
(a) If the first officer's sidewall receptacle connector keyway is not set at the up position, or
12 o'clock, do the steps that follow:
1) Remove the first officer's sidewall (TASK 25-11-21-000-801 or
TASK 25-11-21-000-805).
2) Remove the four screws [3] and four washers [2] at the sidewall receptacle
connector.
3) Turn the sidewall receptacle connector keyway to the up position, or 12 o'clock, and
install the screws and washers.
4) Install the first officer's sidewall (TASK 25-11-21-400-801 or
TASK 25-11-21-400-805).
SUBTASK 30-41-00-210-014
(8) Examine the position of the first officer's window receptacle connector keyway.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
30-41-00
Page 602
D633A101-ILF Oct 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
