"CAUTION, ENSURE POWER OFF. AFTER INSTALLATION OF FEEDER CABLES,
LOOSEN 6 SCREWS ONE FULL TURN (ACCESSED THROUGH THE IN COVER).
THEN RE-TORQUE TO 23-26 INCH-POUNDS USING A 9/64 IN HEX DRIVER."
NOTE: Do not do re-torque on airplanes with new rigid bus assemblies, (WITH SB24-1128)
(POST PRR 38317).
(a) Access to these screws is gained through six holes above and adjacent to the terminal
studs.
(b) Loosen the screws one full turn, then tighten the screws to 25 ±1 in-lb (3 ±0 N·m).
ILF ALL
SUBTASK 24-21-22-420-004
(5) To install the rigid bus assembly on Power Distribution Panel 1, P91, do the steps that follow:
(a) Install the two electrical connectors on the rigid bus assembly and tighten the two screws.
(b) Install the three nuts [9], lockwashers [10] and washers [11] that hold the bus bars to the
rigid bus assembly.
(c) Tighten the nuts to 22 ±2 in-lb (2 ±1 N·m).
(d) Install the breakers listed below. To install these breakers, do this task: Breaker
Installation, TASK 24-21-41-400-801.
1) These are the circuit breakers:
Power Distribution Panel Number 1, P91
Row Col Number Name
--- --- C00803 AUXILIARY POWER BREAKER
--- --- C00804 BUS TIE BREAKER 1
--- --- C00801 GENERATOR BREAKER 1
SUBTASK 24-21-22-420-005
(6) To install the rigid bus assembly on Power Distribution Panel 2, P92, do the steps that follow:
(a) Install the two electrical connectors on the rigid bus assembly and tighten the two screws.
(b) Install the three nuts [9], lockwashers [10] and washers [11] that hold the bus bars to the
rigid bus assembly.
(c) Tighten the nuts to 22 ±2 in-lb (2 ±1 N·m).
(d) Install the three bolts [12] and washers [13] that hold wires to the terminal posts on the
rigid bus assembly.
NOTE: Use identification tags on wires for correct installation.
(e) Install the breakers listed below. To install these breakers, do this task: Breaker
Installation, TASK 24-21-41-400-801.
1) These are the circuit breakers:
Power Distribution Panel Number 2, P92
Row Col Number Name
--- --- C00805 BUS TIE BREAKER 2
--- --- C00802 GENERATOR BREAKER 2
(f) Do this task: External Power Contactor Installation, TASK 24-41-12-400-801.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-21-22
Page 413
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
