TASK 53-05-03-210-810
12. INTERNAL - GENERAL VISUAL: PASSENGER COMPARTMENT FLOOR STRUCTURE - DRY AREA
(Figure 214)
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
113 Area Above and Outboard of Nose Landing Gear Wheel Well - Left
114 Area Above and Outboard of Nose Landing Gear Wheel Well - Right
117 Electrical and Electronics Compartment - Left
118 Electrical and Electronics Compartment - Right
121 Forward Cargo Compartment - Left
122 Forward Cargo Compartment - Right
125 Air Conditioning Distribution Bay - Left
126 Air Conditioning Distribution Bay - Right
141 Aft Cargo Compartment - Left
142 Aft Cargo Compartment - Right
145 Aft Cargo Compartment Equipment Bay - Left
146 Aft Cargo Compartment Equipment Bay - Right
B. Access Panels
Number Name/Location
117BL Forward Airstair Door
S1101 Area Above And Outboard of Nose Wheel Well Inspection
C. Inspection
SUBTASK 53-05-03-010-008
(1) Open these access panels:
Number Name/Location
117BL Forward Airstair Door
S1101 Area Above And Outboard of Nose Wheel Well Inspection
NOTE: Remove ceiling and sidewall panels as required. Remove/displace insulation blankets
as required. Remove or displace auxiliary fuel tank as required (business jet only).
Remove forward airstairs and airstairs compartment (if installed).
SUBTASK 53-05-03-210-010
(2) Do a General Visual inspection of the passenger compartment floor structure in dry areas
(away from doors, galleys and lavs) from lower lobe.
SUBTASK 53-05-03-910-012
(3) 737-6789 Basic Task Description, AMM Task 51-05-01-210-808.
SUBTASK 53-05-03-410-008
(4) Close these access panels:
Number Name/Location
117BL Forward Airstair Door
S1101 Area Above And Outboard of Nose Wheel Well Inspection
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 230
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
