TASK 53-05-03-210-843
54. INTERNAL - GENERAL VISUAL: VERTICAL FIN FRONT SPAR FITTING
(Figure 260)
NOTE: This procedure is a scheduled maintenance task.
A. References
Reference Title
51-05-01-210-804 737-6789 Basic Task Description (P/B 201)
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-2032 Sling Equipment - Vertical Fin
737-600, -700, -800
Part #: C55010-33 Supplier: 81205
Opt Part #: C55010-1 Supplier: 81205
C. Consumable Materials
Reference Description Specification
B00083 Solvent - VM&P Naphthas TT-N-95 Type II, ASTM
D-3735 Type III
D00015 Grease - Aircraft Bearing (Use BMS 3-24 until
existing stocks are depleted, BMS 3-33
supersedes BMS 3-24)
BMS3-24 (Superseded
by BMS3-33)
D50004 Compound - Antiseize BMS3-28
D. Location Zones
Zone Area
322 Vertical Fin - Removable Fin Leading Edge
E. Access Panels
Number Name/Location
323AL Vertical Fin, Front Spar Access Door
323AR Vertical Fin, Front Spar Access Door
323BL Vertical Fin, Forward Fin Access Door
323BR Vertical Fin, Forward Fin Access Door
F. Inspection
SUBTASK 53-05-03-480-001
(1) Install the sling equipment, SPL-2032.
SUBTASK 53-05-03-010-040
(2) Open these access panels:
Number Name/Location
323AL Vertical Fin, Front Spar Access Door
323AR Vertical Fin, Front Spar Access Door
323BL Vertical Fin, Forward Fin Access Door
323BR Vertical Fin, Forward Fin Access Door
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 298.81
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
