(Continued)
AMM Item Description AIPC Reference AIPC Effectivity
1 (cont.) 30-42-21-01A-035 ILF 304, 308, 314, 315,
317, 406, 409, 410, 412,
416, 424, 429, 451,
501-504, 507, 514, 524,
536, 541
30-42-21-01A-075 ILF 301, 304, 308, 310,
314, 315, 317-319, 323,
401, 402, 405, 406, 409,
410, 412, 416, 424, 425,
427-429, 451, 452,
501-504, 507-510,
512-516, 518-520,
523-528, 530-533, 536,
541, 542, 552, 571, 572,
703, 707, 708
30-42-21-01A-080 ILF 301, 304, 308, 310,
314, 315, 317-319, 323,
401, 402, 405, 406, 409,
410, 412, 416, 424, 425,
427-429, 451, 452,
501-504, 507-510,
512-516, 518-520,
523-528, 530-533, 536,
541, 542, 552, 571, 572,
703, 707, 708
F. Location Zones
Zone Area
211 Flight Compartment - Left
212 Flight Compartment - Right
G. Wiper Motor/Converter Installation
SUBTASK 30-42-21-100-001
CAUTION
YOU MUST BE CAREFUL WHEN YOU INSTALL THE WIPER MOTOR/
CONVERTER. THE WIPER SHAFT MAY TEAR THE RUBBER SEAL WHERE
THE SHAFT PIERCES THE AIRPLANE SKIN.
(1) Put the wiper motor converter [1] into position.
SUBTASK 30-42-21-400-001
(2) Install the screws [2] and washers [3].
SUBTASK 30-42-21-100-002
(3) Clean the ground wire terminal mating surface and the ground stud on the airplane structure
(SWPM 20-20-00).
(a) Use a cotton wiper, G00034, made moist with alcohol, B00130.
(b) Immediately dry the surfaces with a new cotton wiper.
SUBTASK 30-42-21-420-001
(4) Connect the ground wire to the wiper motor/convertor.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
30-42-21
Page 409
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
