LIGHTNING DIVERTER STRIPS - MAINTENANCE PRACTICES
1. General
A. This procedure contains three tasks:
(1) The first task is the removal of the lightning diverter strips.
(2) The second task is the installation of the lightning diverter strips.
(3) The third task is the adjustment/test of the lightning diverter strips.
B. You must repair the damaged radome surface before you install the new lightning diverter strips.
TASK 53-52-03-000-801
2. Remove the Lightning Diverter Strips
(Figure 201)
A. References
Reference Title
53-52-00-010-802 Nose Radome - Open (P/B 201)
B. Consumable Materials
Reference Description Specification
B00083 Solvent - VM&P Naphthas TT-N-95 Type II, ASTM
D-3735 Type III
G00034 Cotton Wiper - Process Cleaning Absorbent
Wiper (Cheesecloth, Gauze)
BMS15-5 Class A
C. Location Zones
Zone Area
111 Radome
D. Procedure
SUBTASK 53-52-03-010-001
(1) Do this task: Nose Radome - Open, TASK 53-52-00-010-802.
SUBTASK 53-52-03-020-001
(2) Remove the screws that attach the applicable diverter strip [3] to the nose radome [1]
(Figure 202).
SUBTASK 53-52-03-020-002
(3) Remove the diverter strip [3] from the nose radome [1].
SUBTASK 53-52-03-100-001
(4) Remove all unwanted material from the nose radome [1] surface.
SUBTASK 53-52-03-100-002
(5) Clean the nose radome [1] surface with a cotton wiper, G00034 that is moist with solvent,
B00083.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-52-03
Page 201
D633A101-ILF Feb 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
