CONTROL CABIN WINDOW ANTI-ICING SYSTEM - ADJUSTMENT/TEST
1. General
A. This procedure contains scheduled maintenance task data.
B. This procedure has a task to do an operational test of the window heat system.
TASK 30-41-00-710-801
2. Window Heat System - Operational Test
(Figure 501)
A. General
(1) This test makes sure the control cabin window anti-icing system provides heat to these control
cabin windows:
(a) Front windows
(b) Side windows
ILF 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 424, 425, 427-429, 507, 533, 535, 537, 556, 557,
568, 583, 588, 592-596, 671, 672, 832, 836, 837, 841, 842, 968-970, 972, 973, 980-999; ILF 412 POST SB
737-30-1046
(c) Number 3 window
ILF 502, 503, 514, 524, 707-710; ILF 101, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 332-399, 401, 409,
410, 412, 416, 424, 425, 427-429, 451, 501, 504, 507, 508, 513, 515, 516, 518, 531-533, 535-537, 541, 542, 552,
556, 557, 571-574, 576, 686, 803-813, 821, 822, 831, 854-856, 861-863, 871-873 PRE SB 737-56-1017
(d) Number 4 and 5 windows.
ILF ALL
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
COM-1572 Thermometer - Infrared, Intrinsically Safe
737-600, -700, -800
Part #: 568 Ex Supplier: 89536
Opt Part #: DHS24XC-FM Supplier: 08086
Opt Part #: DHS24XF-FM Supplier: 08086
Opt Part #: EX-MP4 A Supplier: 3GT36
Opt Part #: IR-16L3 IS Supplier: 75037
STD-1179
Tester - Pyrometer
C. Location Zones
Zone Area
211 Flight Compartment - Left
212 Flight Compartment - Right
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
30-41-00
Page 501
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
