(e) AIRCRAFT ID: (737)
SUBTASK 47-31-02-740-080
(3) Continue to push the down arrow to see all of the System Configuration items.
F. I/O Monitor List
SUBTASK 47-31-02-740-055
(1) Push the down arrow or NO button on the other function list until I/O Monitor? shows on the
display.
(a) Push the YES button.
1) Make sure that the menu item from the I/O monitor list Analog Inputs? shows on the
display.
SUBTASK 47-31-02-740-082
(2) These are the menu items for the I/O Monitor list:
(a) Analog Inputs?
(b) Discrete Inputs?
(c) Outputs?
(d) Oxygen Sensor?
SUBTASK 47-31-02-740-083
(3) Continue to push the down arrow to see all of menu items for the I/O Monitor list.
G. Analog Inputs List
SUBTASK 47-31-02-740-084
(1) Make sure that ANALOG INPUTS? from the I/O monitor list shows.
(a) Push the YES button.
1) Make sure that TASMI 1: XXX F from the Analog Input list shows on the display.
SUBTASK 47-31-02-740-086
(2) These are the menu items from the Analog Input list:
(a) TASMI 1: XXX F
TASMI 2: XXX F
(b) DPHI: XXX.Xpsid
DPMID: NA
(c) PALT: XXXXX ft
PB: YYY.Y psig
(d) TOTAL AIR TEMP:
NA
SUBTASK 47-31-02-740-087
(3) Continue to push the down arrow to see all of menu items for the Analog Input list.
H. Discrete Inputs List
SUBTASK 47-31-02-740-057
(1) Push the down/up arrow or the NO button on the I/O Monitor list.
(a) Make sure that Discrete Inputs? shows on the display.
SUBTASK 47-31-02-740-088
(2) Push the YES button.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-31-02
Page 247
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
