A. Location Zones
Zone Area
191 Lower Wing-To-Body Fairing - Forward of Wing Box
195 Above Wing, Wing-To-Body Fairing - Left
196 Above Wing, Wing-To-Body Fairing - Right
B. Access Panels
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
191AR Forward Wing To Body Fairing Panel - Upper
195AL Wing To Body Fairing - Left Side
195AR Wing To Body Fairing - Right Side
C. Inspection
SUBTASK 53-05-02-010-018
(1) Open this access panel on the Left side:
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
195AL Wing To Body Fairing - Left Side
Open these access panels on the Right side:
Number Name/Location
191AR Forward Wing To Body Fairing Panel - Upper
195AR Wing To Body Fairing - Right Side
NOTE: Remove or displace wing to body fairings as required to perform this inspection.
SUBTASK 53-05-02-211-016
(2) Do a Detailed inspection of the fuselage skin panels under the Wing to Body Fairing from Sta
360 to Sta 540.
See Doc D626A001-DTR, DTR check form 53-30-02-4 for alternative inspections.
SUBTASK 53-05-02-410-016
(3) Close these access panels on the Left side:
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
195AL Wing To Body Fairing - Left Side
Close these access panels on the Right side:
Number Name/Location
191AR Forward Wing To Body Fairing Panel - Upper
195AR Wing To Body Fairing - Right Side
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-02
Page 222
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
