TASK 24-21-52-400-801
3. Generator Drive and Standby Power Module Installation
(Figure 401)
A. General
(1) The Generator Drive and Standby Power Module, P5-5, is located on the P5 Overhead Panel
in the flight compartment.
B. References
Reference Title
24-11-00-700-802 Number 1 IDG - Operational Test (P/B 501)
24-11-00-700-803 Operational Test For Number 2 IDG (P/B 501)
24-22-00-860-812 Remove Electrical Power (P/B 201)
24-34-00-710-801 The Operational Test of the Standby Power System (P/B 501)
24-34-00-710-802 The Operational Test of the Standby Power System (P/B 501)
C. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 Module 24-21-52-01-050 ILF 401, 405, 416,
508-510, 523, 525, 536,
541
24-21-52-01B-050 ILF 301, 304, 308, 310,
314, 507
24-21-52-01C-050 ILF 406, 409, 410, 412,
424, 425, 427-429, 451,
501-504, 512-516, 524
24-21-52-02-020 ILF 315, 317-319, 323,
402, 452, 518-520,
526-528, 530-533, 542,
552, 571, 572, 703, 707,
708
24-21-52-03-010 ILF 101, 151, 156-199,
331-399, 491-500, 535,
537, 553-557, 559-564,
567-569, 573-577, 581,
583, 585, 588-590, 671,
672, 686, 709, 710,
804-807, 812, 821, 822,
831, 832, 836, 837, 841,
842, 851, 852, 854-858,
861-863, 871-874, 947,
948, 968-973, 980-999
24-21-52-04-010 ILF 592-599, 601-603,
606, 607, 610-615, 620,
625-627, 691-699,
833-835, 838
D. Location Zones
Zone Area
211 Flight Compartment - Left
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-21-52
Page 404
D633A101-ILF Jun 15/2019
