STARTER - REMOVAL/INSTALLATION
1. General
A. This procedure has two tasks:
(1) Starter Removal
(2) Starter Installation.
TASK 80-11-01-000-801-F00
2. Starter Removal
(Figure 401)
A. General
(1) This task provides the instructions on how to remove the starter.
B. References
Reference Title
71-11-02-010-801-F00 Open the Fan Cowl Panels (P/B 201)
80-11-01-200-801-F00 Starter Magnetic Plug Inspection (P/B 601)
80-11-01-680-801-F00 Starter Servicing (Oil Drain) (P/B 301)
80-11-02-000-801-F00 QAD Adapter Removal (P/B 401)
80-11-02-400-801-F00 QAD Adapter Installation (P/B 401)
C. Location Zones
Zone Area
411 Engine 1 - Engine
421 Engine 2 - Engine
D. Prepare for the Removal
SUBTASK 80-11-01-860-027-F00
(1) For Engine 1, open this circuit breaker and install a safety tag:
CAPT Electrical System Panel, P18-2
Row Col Number Name
B 8 C01103 ENGINE 1 START VALVE
SUBTASK 80-11-01-860-028-F00
(2) For Engine 2, open this circuit breaker and install a safety tag:
F/O Electrical System Panel, P6-2
Row Col Number Name
C 4 C00154 ENGINE 2 START VALVE
SUBTASK 80-11-01-010-015-F00
(3) Do this task: Open the Fan Cowl Panels, TASK 71-11-02-010-801-F00.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
80-11-01
Page 401
D633A101-ILF Oct 15/2018
