CONDUCTOR STRAPS - REMOVAL/INSTALLATION
1. General
A. This procedure contains two task:
(1) The first task is for the removal of the conductor straps [2].
(2) The second task is for the installation of the conductor straps [2].
TASK 53-52-03-000-802
2. Remove the Conductor Straps
(Figure 401)
A. General
(1) This task includes the steps to remove the conductor straps [2] from the nose radome [1].
B. References
Reference Title
53-52-03-000-801 Remove the Lightning Diverter Strips (P/B 201)
SRM 51-00-10 GENERAL SEALANT REMOVAL PRECAUTIONS
C. Consumable Materials
Reference Description Specification
B00083 Solvent - VM&P Naphthas TT-N-95 Type II, ASTM
D-3735 Type III
D. Location Zones
Zone Area
111 Radome
E. Procedure
SUBTASK 53-52-03-010-003
(1) Remove the applicable diverter strips [3], do this task: Remove the Lightning Diverter Strips,
TASK 53-52-03-000-801.
(2) Remove the applicable conductor straps [2], refer to SRM 51-00-10.
SUBTASK 53-52-03-100-004
(3) Clean nose radome [1] surface around insert hole with a rag moistened with solvent, B00083
and let dry.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-52-03
Page 401
D633A101-ILF Feb 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
