E. Location Zones
Zone Area
116 Nose Landing Gear Wheel Well - Right
F. Access Panels
Number Name/Location
114AR External Power Receptacle Door
G. Prepare for the Removal
SUBTASK 24-41-11-860-013-001
(1) Do this task: Remove Electrical Power, TASK 24-22-00-860-812.
SUBTASK 24-41-11-010-014-001
(2) Open this access panel:
Number Name/Location
114AR External Power Receptacle Door
SUBTASK 24-41-11-020-007-001
(3) Remove External Power Plug from the receptacle, if it is installed.
SUBTASK 24-41-11-930-005-001
WARNING
PUT A DO-NOT-OPERATE TAG ON THE EXTERNAL POWER RECEPTACLE.
IF YOU DO NOT OBEY THIS INSTRUCTION, INJURIES TO PERSONS CAN
OCCUR.
(4) Attach a DO-NOT-OPERATE tag to the external power receptacle.
SUBTASK 24-41-11-010-015-001
(5) Open access panel on forward right hand side of nose gear wheel well, to get access to the
back of the receptacle.
H. External Power Receptacle Removal
SUBTASK 24-41-11-020-008-001
(1) Do these steps to remove the electrical leads from the receptacle [1]:
(a) Bend the ears at the two corners of the protective boot [14] away from the cover [9].
(b) Pull the protective boot [14] away from the cover [9].
(c) Remove the nuts [8] and washers [7] that attach the cover [9] to the receptacle [1].
(d) Remove the cover [9].
(e) Remove the dielectric separator [6].
(f) Attach identification tags on the electrical leads [13] and electrical leads [2].
(g) Remove the bolts [10], lock washers [11], and washers [12] that attach the electrical
leads [13] to the receptacle [1].
(h) Remove the nuts [5], lock washers [4], and washers [3] that attach the electrical leads [2]
to the receptacle [1].
(i) Remove the electrical leads [13] and electrical leads [2] from the receptacle [1].
SUBTASK 24-41-11-020-012-001
(2) Do these steps to remove the receptacle [1]
(a) Remove the nuts [17] and washers [16] that attach the shield [18] to the receptacle [1].
(b) Remove the shield [18].
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-41-11
Config 1
Page 402
D633A101-ILF Oct 15/2019
