(Continued)
AMM Item Description AIPC Reference AIPC Effectivity
7 (cont.) 30-11-12-01A-030 ILF 101, 151, 156-199,
301, 304, 308, 310, 314,
315, 317-319, 323,
331-399, 402, 405, 410,
416, 424, 425, 427-429,
451, 452, 491-504,
507-510, 512-516,
518-520, 523-528,
530-533, 535-537, 541,
542, 552-557, 559-564,
567-569, 571-577, 581,
583, 585, 588-590,
592-599, 601-603, 606,
607, 610-615, 620,
625-627, 671, 672, 686,
691-699, 703, 707-710,
803-813, 821, 822,
831-838, 841, 842, 851,
852, 854-858, 861-863,
871-874, 947, 948,
968-973, 980-999
F. Location Zones
Zone Area
411 Engine 1 - Engine
421 Engine 2 - Engine
G. Prepare for the Installation
SUBTASK 30-11-12-860-012
(1) Make sure that these circuit breakers are open and have safety tags:
CAPT Electrical System Panel, P18-3
Row Col Number Name
A 1 C00146 ANTI-ICE & RAIN WING ANTI-ICE VALVE
A 6 C00148 ANTI-ICE & RAIN ENG 1 & WING CONT
H. Ground Wing Thermal Anti-Icing Solenoid Valve Installation
SUBTASK 30-11-12-420-001
(1) Position the solenoid valve [7] and spacer [1] on the strut bracket.
SUBTASK 30-11-12-420-002
(2) Secure the solenoid valve [7] with the bolts [6].
SUBTASK 30-11-12-420-003
(3) Install the seal [2] and union [3].
(a) Apply compound, D50004, to the threads of the union [3].
SUBTASK 30-11-12-420-005
(4) Install the tube [4].
SUBTASK 30-11-12-420-007
(5) Connect the electrical connector [5] to the solenoid valve [7].
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
30-11-12
Page 408
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
