TASK 24-31-41-400-801
3. Dual Battery RCCB Installation
(Figure 401, Figure 402)
A. General
(1) The Dual Battery RCCB, C1212, is located on the J9 Battery Shield in the Main Equipment
Center.
B. References
Reference Title
24-22-00-860-813 Supply External Power (P/B 201)
24-22-00-860-814 Remove External Power (P/B 201)
24-31-21-710-801 Main Battery Charger Operational Test (P/B 501)
24-31-31-710-801 Auxiliary Battery Charger Operational Test (P/B 501)
SWPM 20-83-00 Standard Wiring Practices Manual
C. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 Dual Battery RCCB 24-31-41-02-015 ILF 101, 151, 156-199,
301, 304, 308, 310, 314,
315, 317-319, 323,
331-399, 401, 402, 405,
406, 409, 410, 412, 416,
424, 425, 427-429, 451,
452, 491, 492, 501-504,
507-510, 512-516,
518-520, 523-528,
530-533, 535-537, 541,
542, 552-557, 559,
571-577, 703, 803-813,
821, 822, 831, 832, 836,
837
24-31-41-03-015 ILF 493-500, 563, 564,
597-599, 625-627
24-34-31-02-017 ILF 560, 561, 567-569,
581, 583, 585, 589, 590,
601-603, 606, 607,
610-615, 620, 671, 672,
691-699, 835, 838, 841,
842, 851, 852, 857, 858,
947, 948, 968-973,
980-999
D. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
121 Forward Cargo Compartment - Left
122 Forward Cargo Compartment - Right
211 Flight Compartment - Left
212 Flight Compartment - Right
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-41
Page 409
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401,
402, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510,
512-516, 518-520, 523-528, 530-533, 535-537, 541, 542, 552-557, 559-561, 563,
564, 567-569, 571-577, 581, 583, 585, 589, 590, 597-599, 601-603, 606, 607,
610-615, 620, 625-627, 671, 672, 691-699, 703, 803-813, 821, 822, 831, 832,
835-838, 841, 842, 851, 852, 857, 858, 947, 948, 968-973, 980-999
