TASK 53-05-03-210-826
29. INTERNAL - GENERAL VISUAL: AREA AFT OF CARGO COMPARTMENT
(Figure 232)
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
145 Aft Cargo Compartment Equipment Bay - Left
146 Aft Cargo Compartment Equipment Bay - Right
B. Access Panels
Number Name/Location
S1403 Area Aft of Cargo Compartment Inspection
C. Inspection
SUBTASK 53-05-03-010-023
(1) Special Access:
Number Name/Location
S1403 Area Aft of Cargo Compartment Inspection
NOTE: Remove aft cargo compartment aft bulkhead panel and potable water tank.
Remove/displace insulation blankets as required.
SUBTASK 53-05-03-210-026
(2) Do a General Visual inspection of the area aft of cargo compartment, including:
1. Skin panels (skins, frames, stringers), longitudinal lap splices, circumferential skin and
stringer splices.
2. Aft entry and galley door cutout surround structure in lower lobe.
3. STA 1016 bulkhead, including chords, pressure web, stiffeners, chord/web attachments.
4. Stringer splice fittings and tension bolts at STA 1016.
5. For the -800BCF, frame reinforcement at STA 967 at S-18 to S-21, at STA 986.5 inspect
floor beam to frame clip reinforcement and frame reinforcement at S-18 to S-22.
SUBTASK 53-05-03-910-031
(3) 737-6789 Basic Task Description, AMM Task 51-05-01-210-808.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 298
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
