B. Location Zones
Zone Area
113 Area Above and Outboard of Nose Landing Gear Wheel Well - Left
114 Area Above and Outboard of Nose Landing Gear Wheel Well - Right
115 Nose Landing Gear Wheel Well - Left
116 Nose Landing Gear Wheel Well - Right
C. Access Panels
Number Name/Location
113BW Forward Nose Wheel Well Panel
114BW Forward Nose Wheel Well Panel
117A Electronic Equipment Access Door
D. Inspection
SUBTASK 53-05-02-010-016
(1) Open these access panels on the Left side:
Number Name/Location
113BW Forward Nose Wheel Well Panel
117A Electronic Equipment Access Door
Open these access panels on the Right side:
Number Name/Location
114BW Forward Nose Wheel Well Panel
117A Electronic Equipment Access Door
(a) Do this task: Nose Wheel Well Access Panels - Removal, TASK 53-14-01-020-801.
SUBTASK 53-05-02-211-011
(2) Do a Detailed inspection of the inboard and outboard fitting segments of the Trunnion Support
Fitting around the pin socket at BS 294.5, WL 156.1, and BL 16.
See Doc. D626A001-DTR, DTR check form 53-10-20-3 for alternative inspections.
SUBTASK 53-05-02-410-014
(3) Close these access panels on the Left Side:
Number Name/Location
113BW Forward Nose Wheel Well Panel
117A Electronic Equipment Access Door
Close these access panels on the Right Side:
Number Name/Location
114BW Forward Nose Wheel Well Panel
117A Electronic Equipment Access Door
(a) Do this task: Nose Wheel Well Access Panels - Installation, TASK 53-14-01-420-801.
END OF TASK
TASK 53-05-02-211-812
33. INTERNAL - DETAILED: AIR STAIR DOOR CUTOUT
NOTE: This procedure is a scheduled maintenance task.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-02
Page 216
D633A101-ILF Oct 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
