(a) Ram Air Intake (SECTION 21-51)
(b) Lights (SECTION 33-44)
E. Forward Wing-To-Body Fairing Panels Removal Procedure
SUBTASK 53-51-21-010-001
(1) Remove sealant from the edge of the applicable panel.
NOTE: You can remove a section of the fillet seal (TASK 51-31-00-160-801).
SUBTASK 53-51-21-020-003
(2) Do these steps to remove the applicable fairing panels:
NOTE: Hold the fairing panel until all the fasteners have been removed.
NOTE: Identify the fasteners to install them in the same locations.
(a) Zone 191:
1) Remove the fasteners for access panel [7]:
Number Name/Location
191AL Forward Wing To Body Fairing Panel - Upper
2) Remove the fasteners for access panel [1]:
Number Name/Location
191AR Forward Wing To Body Fairing Panel - Upper
3) Remove the fasteners for access panel [6]:
Number Name/Location
191BL Forward Wing To Body Fairing Panel, Ram Air Inlet
4) Remove the fasteners for access panel [2]:
Number Name/Location
191BR Forward Wing To Body Fairing Panel, Ram Air Inlet
5) Remove the fasteners for access panel [5]:
Number Name/Location
191CL Forward Wing To Body Fairing Panel - Middle
6) Remove the fasteners for access panel [3]:
Number Name/Location
191CR Forward Wing To Body Fairing Panel - Middle
7) Remove the fasteners for access panel [4]:
Number Name/Location
191D Forward Wing To Body Fairing Panel - Lower
8) Remove the fasteners for access panel [11]:
Number Name/Location
191E Low Pressure ECS Panel - Forward
9) Remove the fasteners for access panel [9]:
Number Name/Location
191FL Forward Wing To Body Fairing Panel - Mid Fairing, Above Ram Air
Inlet
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-51-21
Page 402
D633A101-ILF Oct 15/2014
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
