ENGINE START LEVER LAMPS - REMOVAL/INSTALLATION
1. General
A. This procedure contains two tasks:
(1) The removal of the Engine Start Lever Lamps.
(2) The Installation of the Engine Start Lever Lamps.
TASK 76-11-02-000-801-F00
2. Engine Start Lever Lamps Removal
A. General
(1) This task includes the steps to remove the Engine Start Lever Lamps.
(2) The lamps are installed in the Engine Start Lever Caps.
B. Location Zones
Zone Area
211 Flight Compartment - Left
212 Flight Compartment - Right
C. Prepare for the Removal
SUBTASK 76-11-02-860-026-F00
(1) For engine 1, open these circuit breakers and install safety tags:
CAPT Electrical System Panel, P18-2
Row Col Number Name
B 1 C01316 ENGINE 1 START LEVER CHAN A
B 2 C01317 ENGINE 1 START LEVER CHAN B
(2) For engine 2, open these circuit breakers and install safety tags:
F/O Electrical System Panel, P6-2
Row Col Number Name
B 6 C01318 ENGINE 2 START LEVER CHAN A
B 7 C01319 ENGINE 2 START LEVER CHAN B
D. Lamp Removal
SUBTASK 76-11-02-020-025-F00
CAUTION
YOU MUST BE CAREFUL WHEN YOU REMOVE THE COMPONENTS FROM
THE CONTROL STAND. DAMAGE TO THE SWITCHES, LIGHTS,
LIGHTPLATES, NUTPLATES, WIRE BUNDLES AND THE PAINTED FINISH ON
ALL THE PARTS CAN OCCUR.
(1) Remove the Lens Cap [229] from Engine Start Lever [201] by turning it counterclockwise.
(2) Remove LED Light [230] from the Lens Cap [229].
END OF TASK
