(Continued)
AMM Item Description AIPC Reference AIPC Effectivity
2 (cont.) 80-11-01-01A-070 ILF 317, 406, 424, 425,
427-429, 499, 500, 556,
560-564, 567-569, 581,
583, 585, 588-590,
592-599, 601-603, 606,
607, 610-615, 620,
625-627, 691-699,
833-835, 838, 948,
970-973, 980-999
F. Location Zones
Zone Area
411 Engine 1 - Engine
421 Engine 2 - Engine
G. Prepare for the Inspection
SUBTASK 80-11-01-860-031-F00
(1) For Engine 1, open this circuit breaker and install a safety tag:
CAPT Electrical System Panel, P18-2
Row Col Number Name
B 8 C01103 ENGINE 1 START VALVE
SUBTASK 80-11-01-860-032-F00
(2) For Engine 2, open this circuit breaker and install a safety tag:
F/O Electrical System Panel, P6-2
Row Col Number Name
C 4 C00154 ENGINE 2 START VALVE
SUBTASK 80-11-01-010-016-F00
(3) Do this task: Open the Fan Cowl Panels, TASK 71-11-02-010-801-F00.
H. Starter Magnetic Plug Inspection
SUBTASK 80-11-01-020-001-F00
CAUTION
DO NOT REMOVE THE MAGNETIC PLUG HOUSING OR THE SAFETY
CABLE. THE REMOVAL OF THE MAGNETIC PLUG HOUSING WILL DRAIN
THE OIL FROM THE STARTER. THE OPERATION OF THE STARTER
WITHOUT OIL CAN CAUSE DAMAGE TO THE STARTER.
(1) Remove the magnetic plug [1] as follows:
NOTE: The magnetic plug is a bayonet type.
(a) Push the magnetic plug [1] with your hand and turn it counterclockwise until it stops.
(b) Pull the magnetic plug [1] from the magnetic plug housing.
SUBTASK 80-11-01-211-001-F00
(2) Examine the magnetic plug [1] for the type and quantity of contamination:
(a) Use 10x hand held magnifying lens, STD-1070, to examine the particles:
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
80-11-01
Page 605
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
