WINDSHIELD WIPER ARM - MAINTENANCE PRACTICES
1. General
A. This procedure has these tasks:
(1) Windshield Wiper Arm Removal
(2) Windshield Wiper Arm Installation
(3) Windshield Wiper Arm Force Check/Adjustment
(4) Windshield Wiper Arm Position Adjustment
TASK 30-42-31-000-801
2. Windshield Wiper Arm Removal
(Figure 201)
A. Location Zones
Zone Area
211 Flight Compartment - Left
212 Flight Compartment - Right
B. Procedure
SUBTASK 30-42-31-860-001
WARNING
BEFORE YOU DO MAINTENANCE ON THE WINDSHIELD WIPER SYSTEM,
OPEN THE WINDOW HEAT CIRCUIT BREAKERS. IF THESE CIRCUIT
BREAKERS ARE NOT OPEN DURING MAINTENANCE, YOU CAN GET AN
ELECTRICAL SHOCK WHEN YOU TOUCH THE WINDOW.
(1) Open these circuit breakers and install safety tags:
CAPT Electrical System Panel, P18-3
Row Col Number Name
C 1 C00523 HEATERS CAPT PITOT
D 1 C00226 WINDOW HEAT CONTROL RIGHT FRONT AC
D 2 C00225 WINDOW HEAT CONTROL LEFT SIDE AC
D 5 C00525 HEATERS F/O PITOT
D 6 C00524 HEATERS AUX PITOT
E 1 C00224 WINDOW HEAT CONTROL LEFT FRONT AC
E 2 C00227 WINDOW HEAT CONTROL RIGHT SIDE AC
F/O Electrical System Panel, P6-11
Row Col Number Name
ILF 568, 583, 588, 592-596, 671, 672, 832, 836, 837, 841, 842, 968-970, 972, 973, 980-999
B 7 C01650 WINDOW HEAT POWER L3
ILF 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 424, 425, 427-429, 507, 533, 535, 537,
556, 557
B 7 C00229 WINDOW HEAT POWER L3, L4 & L5
ILF 502, 503, 514, 524, 707-710; ILF 101, 156-199, 409, 410, 412, 416, 451, 501, 504, 508, 513, 515,
516, 518, 531, 532, 536, 541, 542, 552, 571, 572, 574, 576, 803-813, 821, 822, 831, 854-856, 861-863,
871-873 PRE SB 737-56-1017
B 7 C00229 WINDOW HEAT POWER L4 & L5
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
30-42-31
Page 201
D633A101-ILF Oct 15/2019
