(Continued)
Number Name/Location
194GL Aft Wing To Body Fairing Panel
194GR Aft Wing To Body Fairing Panel
C. Inspection
SUBTASK 53-05-02-010-037
(1) Open these access panels on the Left side:
Number Name/Location
194AL Aft Wing To Body Fairing Panel
194FL Aft Wing To Body Fairing Panel
194GL Aft Wing To Body Fairing Panel
Open these access panels on the Right side:
Number Name/Location
194AR Aft Wing To Body Fairing Panel
194FR Aft Wing To Body Fairing Panel
194GR Aft Wing To Body Fairing Panel
NOTE: Remove or displace wing to body fairings as required to perform this inspection.
SUBTASK 53-05-02-211-068
(2) Do a Detailed inspection of the fuselage skin panels under the Wing to Body Fairing from STA
727 to STA 887. (53-60-02-4).
See Doc D626A001-DTR, DTR check form 53-30-02-4 for alternative inspections.
SUBTASK 53-05-02-410-035
(3) Close these access panels on the Left side:
Number Name/Location
194AL Aft Wing To Body Fairing Panel
194FL Aft Wing To Body Fairing Panel
194GL Aft Wing To Body Fairing Panel
Close these access panels on the Right side:
Number Name/Location
194AR Aft Wing To Body Fairing Panel
194FR Aft Wing To Body Fairing Panel
194GR Aft Wing To Body Fairing Panel
END OF TASK
TASK 53-05-02-250-940
187. EXTERNAL - SPECIAL DETAILED: LONGITUDINAL LAP SPLICE
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
241 Aft Passenger Compartment - Station 663.75 to Aft Pressure Bulkhead - Left
242 Aft Passenger Compartment - Station 663.75 to Aft Pressure Bulkhead - Right
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-02
Page 298.17
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
