TASK 53-05-03-210-809
11. INTERNAL - GENERAL VISUAL: AREA ABOVE AND OUTBOARD OF NOSE WHEEL WELL
(Figure 213)
NOTE: This procedure is a scheduled maintenance task.
A. References
Reference Title
53-14-01-020-801 Nose Wheel Well Access Panels - Removal (P/B 401)
53-14-01-420-801 Nose Wheel Well Access Panels - Installation (P/B 401)
B. Location Zones
Zone Area
113 Area Above and Outboard of Nose Landing Gear Wheel Well - Left
114 Area Above and Outboard of Nose Landing Gear Wheel Well - Right
C. Access Panels
Number Name/Location
113AC Fwd Nose Wheel Well Upper Access Panel
113AW Forward Nose Wheel Well Panel
113BW Forward Nose Wheel Well Panel
114AC Fwd Nose Wheel Well Upper Access Panel
114AW Forward Nose Wheel Well Panel
114BW Forward Nose Wheel Well Panel
S1101 Area Above And Outboard of Nose Wheel Well Inspection
D. Inspection
SUBTASK 53-05-03-010-007
(1) Open these access panels:
Number Name/Location
113AC Fwd Nose Wheel Well Upper Access Panel
113AW Forward Nose Wheel Well Panel
113BW Forward Nose Wheel Well Panel
114AC Fwd Nose Wheel Well Upper Access Panel
114AW Forward Nose Wheel Well Panel
114BW Forward Nose Wheel Well Panel
NOTE: Access through nose wheel well side and top access panels, and through access
panel in crew floor. Remove/displace insulation blankets as required.
(a) Do this task: Nose Wheel Well Access Panels - Removal, TASK 53-14-01-020-801.
SUBTASK 53-05-03-010-081
(2) Open this access panel:
Number Name/Location
S1101 Area Above And Outboard of Nose Wheel Well Inspection
NOTE: Access through nose wheel well side and top access panels, and through access
panel in crew floor. Remove/displace insulation blankets as required.
SUBTASK 53-05-03-210-009
(3) Do a General Visual inspection of the fuselage lower lobe from canted bulkhead (Sta 224.8 to
227.8) to Sta 294, including:
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 226
D633A101-ILF Oct 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
