F. Thermal Switch Installation Test
SUBTASK 30-41-31-710-001
(1) Do a test of the thermal switch [2].
(a) Remove the safety tags and close these circuit breakers:
CAPT Electrical System Panel, P18-3
Row Col Number Name
D 1 C00226 WINDOW HEAT CONTROL RIGHT FRONT AC
D 2 C00225 WINDOW HEAT CONTROL LEFT SIDE AC
E 1 C00224 WINDOW HEAT CONTROL LEFT FRONT AC
E 2 C00227 WINDOW HEAT CONTROL RIGHT SIDE AC
ILF 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 968-970, 972, 973, 980-999
F 1 C00222 WINDOW HEAT CONT RIGHT FRONT DC
F 4 C00223 WINDOW HEAT CONT RIGHT SIDE DC
F 5 C00220 WINDOW HEAT CONT LEFT FRONT DC
F/O Electrical System Panel, P6-11
Row Col Number Name
ILF 568, 583, 588, 592-596, 671, 672, 832, 836, 837, 841, 842, 968-970, 972, 973, 980-999
B 7 C01650 WINDOW HEAT POWER L3
ILF 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 424, 425, 427-429, 507, 533, 535,
537, 556, 557
B 7 C00229 WINDOW HEAT POWER L3, L4 & L5
ILF 502, 503, 514, 524, 707-710; ILF 101, 156-199, 409, 410, 412, 416, 451, 501, 504, 508, 513,
515, 516, 518, 531, 532, 536, 541, 542, 552, 571, 572, 574, 576, 803-813, 821, 822, 831, 854-856,
861-863, 871-873 PRE SB 737-56-1017
B 7 C00229 WINDOW HEAT POWER L4 & L5
ILF 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 424, 425, 427-429, 502, 503, 507,
514, 524, 533, 535, 537, 556, 557, 568, 583, 588, 592-596, 671, 672, 707-710, 832, 836, 837, 841,
842, 968-970, 972, 973, 980-999; ILF 101, 156-199, 409, 410, 416, 451, 501, 504, 508, 513, 515,
516, 518, 531, 532, 536, 541, 542, 552, 571-574, 576, 686, 803-813, 821, 822, 831, 854-856,
861-863, 871-873 PRE SB 737-56-1017; ILF 412 POST SB 737-30-1046 OR PRE SB
737-56-1017
B 8 C00393 WINDOW HEAT POWER RIGHT SIDE
B 9 C00228 WINDOW HEAT POWER LEFT FRONT
F/O Electrical System Panel, P6-12
Row Col Number Name
ILF 568, 583, 588, 592-596, 671, 672, 832, 836, 837, 841, 842, 968-970, 972, 973, 980-999
B 7 C01649 WINDOW HEAT POWER R3
ILF 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 424, 425, 427-429, 507, 533, 535,
537, 556, 557
B 7 C00395 WINDOW HEAT POWER R3, R4 & R5
ILF 502, 503, 514, 524, 707-710; ILF 101, 156-199, 409, 410, 412, 416, 451, 501, 504, 508, 513,
515, 516, 518, 531, 532, 536, 541, 542, 552, 571, 572, 574, 576, 803-813, 821, 822, 831, 854-856,
861-863, 871-873 PRE SB 737-56-1017
B 7 C00395 WINDOW HEAT POWER R4 & R5
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
30-41-31
Page 408
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 424, 425, 427-429,
502, 503, 507, 514, 524, 533, 535, 537, 556, 557, 568, 583, 588, 592-596, 671, 672,
707-710, 832, 836, 837, 841, 842, 968-970, 972, 973, 980-999; ILF 101, 156-199,
409, 410, 416, 451, 501, 504, 508, 513, 515, 516, 518, 531, 532, 536, 541, 542,
552, 571-574, 576, 686, 803-813, 821, 822, 831, 854-856, 861-863, 871-873 PRE
SB 737-56-1017; ILF 412 POST SB 737-30-1046 OR PRE SB 737-56-1017
