TASK 24-31-21-400-801-001
3. Main Battery Charger Installation
(Figure 401)
A. References
Reference Title
20-10-07-400-801 E/E Box Installation (P/B 201)
20-40-12-400-802 ESDS Handling for Metal Encased Unit Installation (P/B 201)
24-22-00-860-812 Remove Electrical Power (P/B 201)
24-22-00-860-813 Supply External Power (P/B 201)
B. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 Battery charger 24-31-21-01-060 ILF 707, 708
24-31-21-01J-005 ILF 710
C. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
118 Electrical and Electronics Compartment - Right
D. Access Panels
Number Name/Location
117A Electronic Equipment Access Door
E. Main Battery Charger Installation
SUBTASK 24-31-21-910-002-001
CAUTION
DO NOT TOUCH THE BATTERY CHARGER BEFORE YOU DO THE
PROCEDURE FOR DEVICES THAT ARE SENSITIVE TO ELECTROSTATIC
DISCHARGE. ELECTROSTATIC DISCHARGE CAN CAUSE DAMAGE TO THE
BATTERY CHARGER.
(1) Before you touch the battery charger [1], do this task: ESDS Handling for Metal Encased Unit
Installation, TASK 20-40-12-400-802.
SUBTASK 24-31-21-420-001-001
(2) Install the battery charger [1] on the E2-1 shelf, do this task: E/E Box Installation,
TASK 20-10-07-400-801.
SUBTASK 24-31-21-860-002-001
(3) Remove the safety tags and close these circuit breakers:
Battery Shield, J9
Row Col Number Name
A 4 C00142 BATTERY CHARGER
Power Distribution Panel Number 2, P92
Row Col Number Name
E 1 C00809 BAT CHGR
F. Main Battery Charger Installation Test
SUBTASK 24-31-21-710-001-001
(1) Do a check of the battery charger [1] per the steps that follow:
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-21
Config 1
Page 404
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 707-710
